Aluminum Magnesium Alloy Outdoor Led Video Wall 3840Hz Led Screen For Advertisement
| Place of Origin | China |
|---|---|
| Brand Name | MPLED |
| Certification | CE/ROHS/FCC/ISO/UL |
| Model Number | P3.3 |
| Minimum Order Quantity | 1 |
| Price | Negotiable |
| Packaging Details | flight case/ wooden case/ carton/ it is up to you |
| Delivery Time | 7-10 working days after receive your payment |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 3000sqm |
Product Details
| Product Name | Outdoor Led Video Wall | Warranty | 2 Years |
|---|---|---|---|
| Refresh Frequency | 3840Hz | Ingress Protection | IP65 |
| Signal Input Format | HDMI,DVI,SDI,VGA Etc. | Cabinet Weight | 29KG |
| High Light | 3840Hz IP65 Outdoor Led Video Wall,3840Hz Outdoor Led Video Wall,3840Hz outdoor led screen |
||
Product Description
Aluminum Magnesium Alloy Outdoor Led Video Wall 3840Hz Led Screen For Advertisement
Aluminum Magnesium Alloy 960x960mm Led Screen For Advertisement
Product presentation
1. The cabinet can be compatible with a variety of module models,P2.5 P3 P4 P5 P6 P8 P10(320x160mm) can be replaced directly.
2. Super strong anti-UV, anti-level 12 storm, anti-severe cold, corrosion resistance, adapt to various harsh environments.
3. Support different sizes to fight each other (left and right).
4. No smear, no flicker, no scan line.
5. Savings in Electricity Costs,300 Sqm, 5 years , Save $200,000 on Electricity Costs.
6. There are quick locks on the top and bottom and left and right sides of the box. Installation is faster. Better flatness and consistency.
7. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc. Yes, you can control in your convenient management. Many screens together? No problem, your laptop can manage all of them whenever and wherever.
| Pixel Pitch | 3.3mm | |||
| LED Lamp | SMD1921 | |||
| LED configuration | SMD 3 in 1 | |||
| Module Size | 320mm x 160mm | |||
| Module pixels | 96x48dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
| Module Quantity(pcs) | 18 | |||
| Cabinet resolution WxH | 290x290dots | |||
| Cabinet Material | magnesium alloy | |||
| Cabinet Weight (kg) | 29 | |||
| Average Power/sqm (watts) | 240 | |||
| Max Power/sqm(watts) | 800 | |||
| Brightness | 5500cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 3.3-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 14 bit | |||
| Refresh frequency | 3840Hz | |||
| Driving mode | 1/12 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | Input Voltage | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
