P4 Outdoor Full Color LED Display Screen 500x1000mm Die Casting Aluminum

Place of Origin Shenzhen China
Brand Name MPLED
Certification CE/ROHS/FCC/ISO/UL
Model Number P4.81
Minimum Order Quantity 1
Price Negotiable
Packaging Details flight case/ wooden case/ carton/ it is up to you
Delivery Time 7-10 working days after receive your payment
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 3000sqm
Product Details
Product Name Outdoor Led Display Board Cabinet Size 500x1000mm
Cabinet Material Aluminum Die Casting Ingress Protection IP65
Signal Input Format HDMI,DVI,SDI,VGA Etc. Input Voltage 110 ~ 240 Volt,60Hz
Brightness 4500-5000cd/㎡ Pixel Pitch 4.81mm
Refresh Frequency 3840hertz Lifetime At 50% Brightness 100000 Hours
High Light

500x1000mm Full Color LED Display

,

ODM P4 Full Color LED Display

,

IP65 p4 outdoor led screen

Leave a Message
Product Description

P4 Outdoor Full Color LED Display Screen 500x1000mm Die Casting Aluminum



Custom Logo Die Casting Aluminum 500x1000mm P4 Outdoor Led Display Board



Product presentation



1. Never black screen even current backup for power supply, when any power supply is not working other power supplies will provide power to keep the screen working.



2. High Precision Curve Lock design (-10° to +10°) is adopted to solve the problem that the old curved lock is difficult to use before. Rotational control, more accurate, easy to use and quickly adjust curve degree.



3. Adopts magnetic adsorption LED panels with ultra thin design, broadside waterproof interface and installation knob.Fast replacement, assemble, disassemble with safety protection.



4. Can be built any shape or size since they are constructed of individual panels you can stack them so they are very tall or really wide.



5. 15 Seconds To Replace A Module,10 seconds to replace a central unit, which can effectively solve major issues on site.



6. Installation Protection ,Automatic edge protection & effective corner protection,Protect the LEDs near the edge of the cabinet, effectively reducing damage by 50% caused during installation,Ensure that the LEDs are free from contact with the ground when the cabinet is placed on the ground.



Pixel Pitch 4.81mm
LED Lamp SMD1921
IC ICN2153
Module Size 250x250mm
Module pixels 52x52dots
Cabinet Size(WxHxD)(mm) 500x1000x88 mm
Module Quantity(pcs) 8
Cabinet resolution WxH 104x208dots
Cabinet Material Aluminum die casting
Cabinet Weight (kg) 14
Average Power/sqm (watts) 200
Max Power/sqm(watts) 650
Brightness 4500-5000cd/㎡
Viewing Angle H:160°, V:120°
Best Viewing Distance 4.81-200 meters
Brightness Control 256 level
Gray scale 16 bit
Refresh frequency 3840hertz
Driving mode 1/16 scan
Input power frequency 50 or 60 Hertz
Input Voltage 110 ~ 240 Volt,60Hz
Blind spot rate <1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP65
Operating temperature ﹣20 ~﹢60 ℃
Operating humidity 10% ~ 90%
Control distance CAT5 cable:<100 m; Single mode fiber:<10 km
Signal input format HDMI,DVI,SDI,VGA etc.
Operating system Windows (2000/XP/Vista/7/8/10)



P4 Outdoor Full Color LED Display Screen 500x1000mm Die Casting Aluminum 0P4 Outdoor Full Color LED Display Screen 500x1000mm Die Casting Aluminum 1



One- Stop Solution Service



1. 3D/CAD engineering drawing to confirm project execution/implementation as presale service within 72 hours.



2. Free CAD drawings for steel structure, signal/power connections of led display which guide for site cable arrangement and structure preparation in advance.



3. 7/24 online remote control service , and local engineer service within 8 hours contact.



4. Free technical training in factory.



5. MPLED engineers will fly to the site if you need local service.



6. Expanding market plan with professional MPLED team over 8 years experience.



7. Multiple options for global transportation, like FOB, CIF, DDP, DDU to most countries.



FAQ



Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and managementSupportAPP/PhoneWIFIIpad/Laptop/PC/Cloud control. It's very easy and convenient to control.

Q2: What is your best service?
A: One to one sales engineer to customer responsibility system. We will do:
1. Know your proiect and provide the best solution for it
2. Track your order and let you know each step and detail of it:
3. Teachyou how to install and use the screen;
4. Care the subsequent use of your screen and ensure vour after -sales service be well





Q3: How about your delivery time?
A: Generally. it will take 15 to 25 days after receiving your advance payment. The spe- cific delivery time depends on the items and the quantity of your order.

Q4: How about your Warranty Term?
A: 2-5year warranty. Structure design,installation problem,program the screen. how to use the screen... don't worry,we have professional after-sale team to solve your any questions after you placed an order. And your exclu-sive sales engineer will also help you get over any problems.



Sole Agent



MPLED cooperated with local team to expand Led display business, and signed sole agent in Saudi Arabia, Egypt, New Zealand, Germany and Indonesia.



Also had local installation and maintenance team in Cambodia, France, Middle East, Indonesia, United States, South Korea, Ghana.
