32x16 Dots Led Perimeter Advertising Boards IP65 Sports Led Display Screen
| Place of Origin | China |
|---|---|
| Brand Name | MPLED |
| Certification | CE/ROHS/FCC/ISO/UL |
| Model Number | P10 |
| Minimum Order Quantity | 1 |
| Price | Negotiable |
| Packaging Details | flight case/ wooden case/ carton/ it is up to you |
| Delivery Time | 10-15 working days after receive your payment |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 3000sqm |
Product Details
| Product Name | Stadium Led Screen | Brightness | 7000cd/sqm |
|---|---|---|---|
| Ingress Protection | IP65 | Warranty | 2 Years |
| Cabinet Size | 960x960mm | Operating Humidity | 10％ ～ 90％ |
| High Light | 32x16 Dots Sports Led Display Screen,IP65 Sports Led Display Screen,IP65 Led Perimeter Advertising Boards |
||
Product Description
32x16 Dots Led Perimeter Advertising Boards IP65 Sports Led Display Screen
Nationstar Novastar Stadium Led Screen Energy Saving Environmental Protection
Product description
1. The LED stadium screen integrates live content and time, and there are three parts of the integral control system. The outdoor P10 LED display adopts three-in-one surface mount technology to enable the display to have a wider viewing angle and a higher refresh rate, thereby ensuring the quality of video playback.
2. The cabinet adopts an adjustable tilt angle design, which can adjust the appropriate tilt angle (75°-90°) according to different environmental requirements, which can meet the viewing needs of on-site audiences.
3. The stadium screen uses a soft mask and a soft material covering the upper part, which can protect the LED lamp beads and avoid obvious injuries caused by collisions.
4. The LED stadium screen uses an efficient optical fiber transmission system, which greatly reduces the delay caused by the transmission distance on the football field, and can ensure that the screen playback is always consistent. At the same time, it also has a dual network cable hot backup function.
5. The waterproof effect is good, with the IP65 protection level, it can fully guarantee the normal operation of the stadium screen in rainy days.
6. The LED stadium screen also has a refresh rate of up to 3840Hz, which greatly meets the needs of dynamic shooting on the sports field and effectively avoids flickering during shooting.
| Pixel Pitch | 10mm | |||
| LED Lamp | SMD3535 | |||
| IC | ICN2037 | |||
| Module Size | 320x160mm | |||
| Module pixels | 32x16 dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108 mm | |||
| Module Quantity(pcs) | 18 | |||
| Cabinet resolution WxH | 96x96dots | |||
| Cabinet Material | Aluminum die casting | |||
| Cabinet Weight (kg) | 29 | |||
| Average Power/sqm (watts) | 240 | |||
| Max Power/sqm(watts) | 800 | |||
| Brightness | 7000cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 10-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 16 bit | |||
| Refresh frequency | 3840hertz | |||
| Driving mode | 1/2 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
