Small Pixel Pitch Full Color LED Display Screen SMD1515 P1.875 P1.923 P2
| Place of Origin | China |
|---|---|
| Brand Name | MPLED |
| Certification | CE/ROHS/FCC/ISO/UL |
| Model Number | P1.8 |
| Minimum Order Quantity | 1 |
| Price | Negotiable |
| Packaging Details | flight case/ wooden case/ carton/ it is up to you |
| Delivery Time | 7-10 working days after receive your payment |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 3000sqm |
Product Details
| Product Name | High Difinition Small Pixel Pitch | Module Size | 320x160mm |
|---|---|---|---|
| Cabinet Size | 640x480mm | Average Power/sqm (watts) | 600 |
| Gray Scale | 16 Bit | Name | Small Pixel Led Display |
| High Light | P1.875 Full Color LED Display,SMD1515 Full Color LED Display,SMD1515 small pixel led display |
||
Product Description
Small Pixel Pitch Full Color LED Display Screen SMD1515 P1.875 P1.923 P2
High Difinition Small Pixel Pitch P1.875 P1.923 P2 Led Display
Product description
1. Modules, receiving cards, and cables can be maintained from the front, greatly reducing labor and steel structaure costs.
2. It can not only help users to improve their work efficiency, but also fully enhance the experience of using LED screens.
3. No need to add additional load-bearing structure, which can effectively reduce installation costs.
4. The cable-free design between the cabinets not only effectively reduces the failure rate but also extends the life of the screen.
5. The world's first golden ratio of 16:9 standard cabinet, Consistent with the pupil ratio of the human eye,Compatible with 2K, 4K and 8K ,Bezel-free.
| Pixel Pitch | 1.8mm | |||
| LED Lamp | SMD1515 | |||
| IC | ICN2153 | |||
| Module Size | 320x160mm | |||
| Module pixels | 172x86dots | |||
| Cabinet Size(WxH)(mm) | 680x480mm | |||
| Module Quantity(pcs) | 6 | |||
| Cabinet resolution WxH | 344x256dots | |||
| Cabinet Material | Aluminum die casting | |||
| Cabinet Weight (kg) | 7 | |||
| Average Power/sqm (watts) | 200 | |||
| Max Power/sqm(watts) | 600 | |||
| Brightness | 800cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 1.8-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 16 bit | |||
| Refresh frequency | 3840hertz | |||
| Driving mode | 1/43 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP30 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
Projects
2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections of led display which guide for site cable arrangement and structure preparation in advance.
3.7/24 online remote control service , and local engineer service within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years experience.
7.Multiple options for global transportation, like FOB, CIF, DDP, DDU to most countries.
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
