ODM Outdoor Advertising Screen Round Transparent P3 Led Panel 3840HZ
| Place of Origin | shenzhen,China |
|---|---|
| Brand Name | H&S LED |
| Certification | CE ROHS FCC |
| Model Number | P3.91 |
| Minimum Order Quantity | 1set |
| Packaging Details | Fight case/Wooden case/Honeycomb Box |
| Delivery Time | 25-35 workdays |
| Payment Terms | L/C, T/T |
| Supply Ability | 100Set/30DAY |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Produce Name | Round LED Diaplay | Pixel Pitch | P3.91mm |
|---|---|---|---|
| Size | Diameter1000mm | Brightness | 3500cd/m² |
| Refresh Rate | 3840HZ | Customization | Customizable Single Sided |
| Input Voltage | AC100-240V | Communication Method | Ethernet/Wifi/3G/4G |
| Control System | Nova/Linsn/Colorlight | Installation Method | Hanging/Stacking/Wall-mounted |
| Highlight | 3840HZ outdoor advertising screen,Transparent P3 outdoor advertising screen,3840HZ p3 led panel |
||
Product Description
High Resolution Glass Transparent P3.91mm P3.9-7.8 Indoor Round Transparent LED Display Screen
Round customized P 3.97-7.81 Transparent Full Color Window Led Display Led Screen for shipping mall bar
|
Pixel Pitch |
3.91-7.81mm |
3.91-7.81mm |
3.91-7.81mm |
|
Density |
32,768 Pixels/㎡ |
32,768 Pixels/㎡ |
32,768 Pixels/㎡ |
|
Pixel Encapsulation |
SMD1921 |
SMD1921 |
SMD1921 |
|
Pixel Configuration |
SMD 3 in 1 |
SMD 3 in 1 |
SMD 3 in 1 |
|
Resolution |
256*128 dots |
381*192 dots |
512*256dot |
|
Diameter |
1m |
1.5m |
2m |
|
Price(USD) |
$2,250 |
$3,300 |
$3,800 |
|
Screen Weight |
20KG/unit |
30KG/unit |
38KG/unit |
|
Brightness |
≥3500nits |
≥3500nits |
≥3500nits |
|
Optimum View Distance |
>3m |
>3m |
>3m |
|
Power Consumption |
400W/unit |
800W/unit |
1200W/unit |
|
Gray Scale |
16 bit |
16 bit |
16 bit |
|
Display Color |
281 Trillions(synchronized) |
281 Trillions(synchronized) |
281 Trillions(synchronized) |
|
Transparency |
60% |
65% |
70% |
|
Operation Power |
AC110~240V |
AC110~240V |
AC110~240V |
|
Control System |
Novastar TB30 |
Novastar TB30 |
Novastar TB30 |
|
Control Mode |
Synchronized and Asynchronized |
Synchronized and Asynchronized |
Synchronized and Asynchronized |
|
Refresh Frequency |
>1,920Hz |
>1,920Hz |
>1,920Hz |
|
Fram Frequency |
>60HZ |
>60HZ |
>60HZ |
|
Surport Signal Input |
S-video, RGBHV, YUV etc. |
S-video, RGBHV, YUV etc. |
S-video, RGBHV, YUV etc. |
|
Control Distance |
UTP140m, Single Mode Fiber 15km |
UTP140m, Single Mode Fiber 15km |
UTP140m, Single Mode Fiber 15km |
|
Brightness Adjustment |
65,536 levels per color (autamatically) |
65,536 levels per color (autamatically) |
65,536 levels per color (autamatically) |
|
Operating Temperature |
-30℃ to 60℃ |
-30℃ to 60℃ |
-30℃ to 60℃ |
|
Operating Humidity |
10%~90% |
10%~90% |
10%~90% |
|
Life Span (50% Brightness) |
>100,000hrs |
>100,000hrs |
>100,000hrs |
|
MTBF |
>10,000hrs |
>10,000hrs |
>10,000hrs |
|
IP (Front/Rear) |
IP43 |
IP43 |
IP43 |
|
Operating environment |
Indoor |
Indoor |
Indoor |
|
LEDs |
Nastionstar |
Nationstar |
Nationsta |
The standard cabinet size of the transparent screen is 1000mm*500mm;
The transparent screen has the advantages of high transparency, light weight, environmental protection, etc.; at the same time, the transparent screen is easier to cut than the ordinary screen, and the shape can be customized at will, such as circle, triangle, semicircle, tree shape, etc.
Customized transparent screens generally have a production cycle of only 15 days, please contact us if you have custom requirements;
Customized Design Available
We offer a customized design package that includes frame, LEDs selection, and different control method options. We can offer SDK of the software to clients to develop their own advertising platform.
