Double Pillar Type P10 Smd Outdoor Led Display Screen 32x16 Dots
| Place of Origin | China |
|---|---|
| Brand Name | MPLED |
| Certification | CE/ROHS/FCC/ISO/UL |
| Model Number | P10 |
| Minimum Order Quantity | 1 |
| Price | Negotiable |
| Packaging Details | flight case/ wooden case/ carton/ it is up to you |
| Delivery Time | 7-10 working days after receive your payment |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 3000sqm |
Product Details
| Product Name | P10 LED Display | Brightness | 6500cd/sqm |
|---|---|---|---|
| Certification | CE,UL,CCC,ROHS,GS | Color | RGB |
| Input Voltage | AC110V - AC240V | Screen Dimension | 960*960 |
| High Light | 32x16 Dots P10 LED Display,ODM P10 Smd Outdoor Led Display,32x16 Dots p10 outdoor led display |
||
Product Description
Double Pillar Type P10 Smd Outdoor Led Display Screen 32x16 Dots
Sports Halls Double Pillar Type Low Power Consumption Panel Led P10
Product description
1. Front and rear maintenance design.
2. Modules, power supplies and control cards can also be disassembled directly from the front without leaving a maintenance channel.
3. There are quick locks on the top and bottom and left and right sides of the box. Installation is faster. Better flatness and consistency.
4. High refresh, high grey scale and high brightness.
5. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc. Yes, you can control in your convenient management. Many screens together? No problem, your laptop can manage all of them whenever and wherever.
6. Designed for working in all weather outdoor environments. High protection grade of IP65 suitable for winter and cold areas like North European countries and Russia, and high temperature like KSA, Oman, UAE, etc.
| Pixel Pitch | 10mm | |||
| LED Lamp | SMD3535 | |||
| LED configuration | SMD 3 in 1 | |||
| Module Size | 320mm x 160mm | |||
| Module pixels | 32x16 dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
| Module Quantity(pcs) | 18 | |||
| Cabinet resolution WxH | 96x96dots | |||
| Cabinet Material | magnesium alloy | |||
| Cabinet Weight (kg) | 29 | |||
| Average Power/sqm (watts) | 240 | |||
| Max Power/sqm(watts) | 800 | |||
| Brightness | 6500cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 10-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 14 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/2 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q1: Is the product customizable?
A: Yes,we can customize the product according to customers' needs, you just need to provide the requirements details.
Q2: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q3:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q4: How about your warranty?
A: Different product offer different time frame warranty, but all product here we offer 2year at least warranty.
Q5: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
Q6: Is the product customizable?
A: Yes,we can customize the product according to customers' needs, you just need to provide the requirements details.
Q7: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q8:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q9: How about your warranty?
A: Different product offer different time frame warranty, but all product here we offer 2year at least warranty.
Q10: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
