Product Details:

Place of Origin: SHENZHEN
Brand Name: H&S LED
Certification: CE ROHS FCC
Model Number: P0.9

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: Fight case/Wooden case/Honeycomb Box
Delivery Time: 20-35 workdays
Payment Terms: L/C, T/T, D/A
Supply Ability: 1000Set
Get Best Price Contact Now

Detail Information

Produce Name: COB LED Display Pixels: 0.9mm
LED Type: COB Pixel Density: 1137777Pixel/m2
Module Size: 150*168.75mm Cabinet Dimension: 600*337.5mm
IP Grade: IP31 Refresh Rate: 3840hz
Viewing Angle: 160°/160° Brightness: ≥1000cd/m²
Used: Indoor Mounted On The Wall Screen Size: Customized
Highlight:

P0.9 cob led display

,

SMD cob led display

,

P1.25 smd led board

Product Description

Ultra high definition led display

P0.9mm LED full colour led display  600*337.5mm HD led Video Wall



Indoor COB LED Display  screen Cabinet 600*337.5mm



Indoor COB P0.9 HD LED screen LED Display 600*337.5mm LED Screens



full colour led display Features:

1. Module size:150x168.75mm, compatible pitch: P0.93/P1.25/p1.56

2. Cabinet size:600x337.5mm,16:9 aspect ratio.

3. Floating connection design between module and cabinet, the module could be fine-tuned.

4. Support double backup of power supply and control system

5. 2K/4K/8K dot to dot matching.

Parameters:



High definition Indoor COB Led Display Specification
pixel pitch P0.93 p1.25 P1.56
lamp COB COB COB
module size(W×H) 150*168.75
module resolution(Pixel/m2) 160*180  120*135  96*108
physcial density(dot/m²) 1137777 640000 409600
cabinet size(W×H) 600 * 337.5 mm
cabinet resolution(W*H)(Pixel) 640*360 480*270 384*216
scanning mode 1/60 1/45 1/48
cabinet Material Diecasting Aluminum
cabinet weight(kg) 5
best viewing distance(m) 0.9 1.25 1.56
gray scale(bit) 14-16
IP Grade IP31
viewing angle H:160 V:160
brightness 600-900cd/㎡
contrast ratio ≥8000:1
color temperature 3200-9300k
refreshrate ≥3840hz
Maximum power 600W/M2
Average power 200W/M2
Operating temperature -20-60℃
Operating Humidity 10-95%RH
Input Voltage AC110-220V±15% 50-60Hz
MTBF(Hours) 50000
Life Time(Hours) 100000



1,COB LED display: Easy to clean with water, eliminating the need for masks, dust, or cloths.

2,All-weather excellence: Utilizes triple protection for superb performance against water, moisture, corrosion, dust, static, oxidation, and UV effects.

3,High Resolution: Provides crisp and clear images, ideal for viewing detailed content and graphics.

4,Brightness and Contrast: Offers high brightness levels and excellent contrast ratios, ensuring visibility even in well-lit environments.

5,Long Lifespan: LED displays have a long operational lifespan, requiring minimal maintenance and replacement.

6,Flexibility: Can be customized in terms of size, shape, and aspect ratio to fit various indoor spaces and applications.

7,Versatility: Suitable for a wide range of indoor applications including retail stores, corporate offices, command centers, broadcast studios, and more.

Fullcolour COB Led Display SMD Board P0.9 P1.25 P1.56 HD led display screen 0Fullcolour COB Led Display SMD Board P0.9 P1.25 P1.56 HD led display screen 1
