Diecasting Aluminum COB Smd Led Display P1.25 3200K-9300K
| Place of Origin | SHENZHEN |
|---|---|
| Brand Name | HSCX |
| Certification | CE ROHS FCC |
| Model Number | P1.25 |
| Minimum Order Quantity | 1set |
| Packaging Details | Fight case/Wooden case/Honeycomb Box |
| Delivery Time | 20-35 workdays |
| Payment Terms | L/C, T/T, D/A |
| Supply Ability | 1000Set |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Produce Name | COB LED Display | Pixels | 1.25mm |
|---|---|---|---|
| LED Type | COB | Pixel Density | 640000Pixel/m2 |
| Module Size | 150*168.75mm | Cabinet Dimension | 600*337.5mm |
| IP Grade | IP31 | Refresh Rate | 3840hz |
| Viewing Angle | 160°/160° | Brightness | ≥1000cd/m² |
| Used | Indoor Mounted On The Wall | Screen Size | Customized |
| Highlight | 3200K smd led display,Diecasting Aluminum smd led display,Diecasting Aluminum p1 25 led display |
||
Product Description
P1.25 LED display Ultra high definition led display
Parameters:
| COB P1.25 Led Display Specification | |
| pixel pitch | p1.25 |
| lamp | COB |
| module size(W×H) | 150*168.75 |
| module resolution(Pixel/m2) | 120*135 |
| physcial density(dot/m²) | 640000 |
| cabinet size(W×H) | 600 * 337.5 mm |
| cabinet resolution(W*H)(Pixel) | 480*270 |
| scanning mode | 1/45 |
| cabinet Material | Diecasting Aluminum |
| cabinet weight(kg) | 5 |
| best viewing distance(m) | 1.25 |
| gray scale(bit) | 14-16 |
| IP Grade | IP31 |
| viewing angle | H:160 V:160 |
| brightness | 600-900cd/㎡ |
| contrast ratio | ≥8000:1 |
| color temperature | 3200-9300k |
| refreshrate | ≥3840hz |
| Maximum power | 600W/M2 |
| Average power | 200W/M2 |
| Operating temperature | -20-60℃ |
| Operating Humidity | 10-95%RH |
| Input Voltage | AC110-220V±15% 50-60Hz |
| MTBF(Hours) | 50000 |
| Life Time(Hours) | 100000 |
1,COB LED display: Easy to clean with water, eliminating the need for masks, dust, or cloths.
2,All-weather excellence: Utilizes triple protection for superb performance against water, moisture, corrosion, dust, static, oxidation, and UV effects.
3,High Resolution: Provides crisp and clear images, ideal for viewing detailed content and graphics.
4,Brightness and Contrast: Offers high brightness levels and excellent contrast ratios, ensuring visibility even in well-lit environments.
5,Long Lifespan: LED displays have a long operational lifespan, requiring minimal maintenance and replacement.
6,Flexibility: Can be customized in terms of size, shape, and aspect ratio to fit various indoor spaces and applications.
7,Versatility: Suitable for a wide range of indoor applications including retail stores, corporate offices, command centers, broadcast studios, and more.
