Outdoor Led Display LED Video Screen P10 Fixed LED Display
Product Details:
| Place of Origin: | SHENZHEN |
| Brand Name: | HSLED |
| Certification: | CE ROHS FCC |
| Model Number: | P10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Packaging Details: | Wooden case/Honeycomb Box/Fight case |
| Delivery Time: | 10-15workdays |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000set |
|
Detail Information |
|||
| Product Name: | Outdoor Fixed LED Display | LED: | SMD3535 |
|---|---|---|---|
| Module Size: | 320mm*160mm | Cabinet Size: | 960mm*960mm |
| Brightness: | 5500cd/sqm | Refresh Rate: | IP65 |
| Input Voltage: | AC110~240V | Screen Dimension: | Customized Size |
| Usage: | Outdoor Adverting Display | Specification: | LED Video Wall |
| Highlight: | Advertising LED Display Screens,Outdoor LED Billboard,Fixed p10 outdoor led display |
||
Product Description
Outdoor Electronic Advertising Led Display Outdoor Full Color LED Video Screen Fixed LED Display
Outdoor Commercial Advertising LED Display
Waterproof advertising led screen large stand digital billboard outdoor led display
Durable and Weather-Resistant Design: This LED screen is designed to withstand various weather conditions, with an IP65 rating and a working temperature range of -20°C to +60°C, ensuring it remains operational in extreme temperatures.
High Brightness and Colorful Display: With a brightness of 6500 nits, this screen provides an excellent viewing experience, even in direct sunlight, and features full-color display capabilities.
Long Lifespan and Warranty: The screen boasts a lifespan of 100,000 hours and a 3-year warranty, providing peace of mind for long-term use and minimal maintenance.
Customizable and Flexible: Available in various screen dimensions and customizable options, this LED screen can be tailored to meet specific user requirements and applications.
Certified and Reliable: Compliant with CE, ROHS, FCC, CCC, and ISO9000 certifications, this product ensures high-quality and reliability for commercial use, such as advertising and information release.
About the product:
Module Size: 320x160mm
Brightness:5000--6000cd/sqm
Refresh Rate:1920-3840HZ
Feature: Each module is fitted witha waterproof strip (front waterproofing)
Maintenance Mode:rear-Maintenance
&. Pixel Pitch: 10mm; Cabinet Size: 960×960mm
&. SMD 3535 LED; High brightness: 7500nits, and brightness adjustable,High intensity.
&. Standard processing technology to ensure each row and each column lamps at the same horizontal line, and ensure light consistency and clear, stability pictures.
&. SD to ensure large viewing angle, up to 120° horizontally and 120° vertically. Image no distortion, no color cast in any angle within this range.
& . Cabinet design lightweight, easy to maintain, IP65 high-performance waterproof and dust resistance.
Specification:
|
Pixel Pitch
|
10mm
|
Type
|
SMD3535
|
|
Chip parameters
|
Red λd:(620-625nm) IV:(800-960mcd)
|
Chip parameters
|
Green λd:(520-525nm) IV:(1350-1650mcd)
|
|
Chip parameters
|
Blue λd:(470-475nm) IV:(330-400mcd)
|
Module Resolution
|
32×16=512(Dots)
|
|
Module Size
|
320×160mm
|
Pixel Density
|
10000 Dots/m2
|
|
Cabinet Resolution
|
96×96=9216(Dots)
|
Cabinet Dimension(W*H*D)
|
960×960×130mm
|
|
Cabinets Material
|
Steel
|
Cabinet Weight
|
39kg
|
|
Brightness
|
≥5500cd/m2
|
Viewing Angle
|
120(Horizontal),120(Vertical)
|
 |
|||
|
Nearest Viewing Distance
|
10m
|
Power Consumption (Max)
|
1000 w/m2
|
|
Power Consumption (Average)
|
300 w/m2
|
Refresh Rate
|
≥1920-3840Hz
|
|
Input Voltage
|
AC110-240V±10%,50/60Hz
|
Grey Scale Levels
|
16bit
|
|
Brightness Adjustment
|
256 color levels,can be adjusted manually and automatically optional
|
Life-span
|
100,000 hours
|
|
Protection Level(front/back)
|
IP65
|
Working Temperature
|
-30℃~50℃
|
|
Humidity
|
15%~85%
|
Drive Mode/Driver Position
|
Constant driving 1/2 Scan,Combined diver board
|
|
Input Signal
|
AVI/MPG/MPEG/TXT.etc
|
Control Mode
|
Synchronization/Asynchronization
|
|
Communication Type
|
Net cable,3G,WIFI(Sold separately)
|
Control Card Input
|
DVI,USB,RJ45,HDMI(Sold separately)
|
Our Features:
1. Front access/Front service LED Display
2. High brightness, visible even with direct sunshine
3. High water proof and dust proof, IP65 both front and rear side
4. Having good lighting accordance and no mosaic
5. Getting vivid effect within any position of the viewing range
6. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
High brightness High refresh 3840hz Waterproof and shockproof
outdoor LED displays deliver clear, brilliant images and prevent distortion andinterruptions, no matter where they are installed.Eye-catching high brightnesscombined with a fast refresh rate means visuals are clearly visible in virtuallyany weather or lighting conditions.
An advanced heat dissipation mechanism heps to prevert overheating, The cabinets are also lP65 ratedboth front and back, which means they are dustproof and safe from powerful water jets, while the cabinet andcomponents inside are waterproof for added reliability in virtually any weather conditions.
Product advantages and uses:
High Brightness and Color Display: This P10 outdoor full color advertisement LED screen boasts an impressive brightness of 5500nits, ensuring vibrant and clear visuals even in direct sunlight. This feature is ideal for users who want to grab attention in outdoor environments, such as airports, shopping malls, or exhibition halls.
Durable and Water-Resistant: With an IP65 protection level, this LED screen is designed to withstand harsh weather conditions, making it suitable for outdoor use in various environments.
Long-Lasting and Energy-Efficient: This product has a lifespan of 100,000 hours and a refresh rate of 3840Hz, ensuring a seamless display experience. It is also energy-efficient, reducing maintenance and operational costs.
Easy Maintenance and Service: The screen features front and rear service, allowing for convenient maintenance and repair. This feature is particularly beneficial for users who want to minimize downtime and reduce maintenance costs.
Customization and Compatibility: As a P10 LED screen, this product is compatible with various applications, including advertising, retail stores, shopping malls, and exhibition halls. It also supports SDK function, making it easy to integrate with existing systems.
Our Advantages:
1. Shenzhen H&S Innovation Technology Co., Ltd is a manufacturer of LED display screens., we provide ODM & OEM service. We provide MOQ of 1 square meter.
2. We only use high quality production material, and every material will be tested strictly before production.
3. We are in service for you before order, during order and after order.
4. Our production line works 24 hours a day, we get goods ready as soon as possible for customers.
5. 72 hours non-stop aging test before shipment to make sure goods shipped out in the best condition.
6. We provide at least 2 years warranty for Outdoor Led Display Outdoor Full Color LED Video Screen Indoor Fixed LED Display.
FAQ:
Q1: Why choose HSLED?
A:High Quality + Strict Quality Control + Aging Time + Prompt Shipping Time + Professional & Quick Reply + Risk Free
Assured Quality + 5 Steps Strict QC + 72 Hours Aging Time + Ship as fast as we can + Superior 99.8% Customer Satisfaction + 2 Years Warranty.
Q2: What's the delivery time?
A: Normally production and testing take about 5 to 15 days, if your order is urgent, we can provide premium processing.
OEM & ODM order may take a little longer time.
Q3: Is HSLED a factory?
A: Shenzhen H&S Innovation Technology Co., Ltd have been one of professional Led Display Outdoor Full Color LED Video Screen Fixed LED Display manufacturer since year 2018, and we have a tech team specially for OEM and ODM production line.
Q4: What kind of LED display do you offer?
A: Our products cover LED full color display for indoor and outdoor, Rental LED Display, LED advertisement display, LED stage display, LED irregular-shape display,Round led display, LED Poster display, LED Pole display etc.
Q5: How is your after sales service?
A: We offer 24-hour online service to help you solve problems. You can contact us at any time when you need support, we have professional support team to support you and solve your problems.
Trade Terms:
1. Payment term: 30% trade assurance (or T/T) deposit before production, 70% balance payment before shipment.
2. Shipping: Be arranged according to your requirement.
3. Load port: Shenzhen, China.
