Double Sided P4 Round Shape Led Display Flexible Digital Screen
Product Details:
Place of Origin: | SHENZHEN |
Brand Name: | HSCX |
Certification: | CE ROHS FCC |
Model Number: | P4 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1set |
---|---|
Packaging Details: | Fight case/Wooden case/Honeycomb Box |
Delivery Time: | 8-25work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 1000set |
Detail Information |
|||
Produce Name: | Ootdoor Round LED Diaplay | Pixels:: | ≥3840Hz |
---|---|---|---|
Customization: | Single Sided/Double Sided | Pixel Composition: | 1R1G1BLED (SMD1921) |
Module Size: | 300mm*300mm | Brightness: | 5500cd/m² |
Shape: | Round | Ip Rating: | IP65 |
Operating Environment: | Ooudoor:-20℃-50℃; | Lifetime: | ≥100,000 Hours |
Highlight: | Flexible round shape led display,P4 round shape led display,P4 led digital screen |
Product Description
Roud Led display screen
Model Number : Round Screen Led Display
Application:Video
Brand Name:H&S
Place of Origin:shenzhen, China
Specification:led
Color:Full color
Refresh rate:1920-3840Hz
Brightness:≥5000cd/㎡
Lifespan:100 000 hours
Warranty:2 Years
Certificate:CE ROHS FCC
PH4.28 Technical Specifications | |||||||
Pixel point parameter | |||||||
1 | LED | SMD1921 | |||||
2 | Pixel Pitch | 4.28mm | |||||
3 | Pixel composition | 1R1G1B | |||||
Module technical parameters | |||||||
1 | Module resolution (W * H) | 70*70dot | |||||
2 | Module size (W * H) | 300mm*300mm | |||||
Screen body technical parameters | |||||||
1 | Full screen size | 640mm*640mm*120mm | |||||
2 | dot density | 54289dot/m² | |||||
3 | screen resolution | One side 140*140 points,Double-sided 280*140 points | |||||
4 | Brightness (white field color temperature 6500K) | 5500cd/m² | |||||
5 | Horizontal view/vertical view | 140°/140° | |||||
6 | Best visual distance (m) | 4-100m | |||||
7 | flatness | ≥99% | |||||
8 | Chroma uniformity | ±0.003 Cx,Cy之内 | |||||
9 | service life | >100,000 Hours Theoretical value | |||||
10 | way to install | Side hanging, Mosaic, wall hanging, lifting | |||||
11 | Protection Class | IP65 | |||||
12 | weight | Single side ≈12KG double side ≈16KG | |||||
System control parameter | |||||||
1 | Signal color processing bits | Red, green, and blue ≥14bit | |||||
2 | type of drive | Constant current drive 1/14 scan | |||||
3 | repetition frequency | 60 frames per second | |||||
4 | refresh rate | ≥3840HZ/S | |||||
5 | maximum power | Single side 200W/ set, double side 400W/ set | |||||
6 | average power | Single side 67W/ set, double side 134W/ set | |||||
7 | Operating Temperature Range | -40°C~+60°C | |||||
8 | Screen color temperature | 2000K-9500K is adjustable | |||||
9 | brilliance control | Manual/automatic/program control | |||||
10 | control mode | Asynchronous control/mobile APP, WIFI, U disk, cloud platform |
Nowadays led logo sign is becoming one the most popular media for Starbucks coffee stores, MacDonald stores, Kentucky stores,other retail chain stores, drug chain stores, etc. We have two different logo sign available: one is P4 outdoor logosign with 512mm , the other is P4outdoor logo sign with 600mm.Now we will explore what makes logo sign attractive,the main reason is like following features shows:
1. High brightness & high contrast ratio makes sharp pictures.Max 55,000nits brightness make it still visible even under the sunshine.While the contrast ratio is around 4,000:1, so dynamic pictures always available;
2. Easy operation, you plug in power switch then the logo sign displays video or pictures automatically;Logo sign can be directly mounted on the wall by normal bolt.You can deliver video to logo sign with your mobile phone, or via GPRS 3g 4g 5g, USB disk, or cloud system which can manager logo sign clusters esp. for logo sign in different cities;
3.Double sides logo with front access led modules makes maintenance easy;
4. IP65 makes completely water-proof;
5. For customs logo sign you only can show one ads, but with led logo sign you can play ads from other clients, then you can get extra income.
