Indoor tile led display

Name: Indoor tile led display
Brand: Shenzhen H&S Innovation Technology Co., Ltd
SKU: P2.5
Price: 1,100.00 USD
Availability: InStock

Product Details

Brand Name: HSCXLED

Certification: CE ROHS FCC KC

Model Number: P2.5

Payment & Shipping Terms

Minimum Order Quantity: 1set

Packaging Details: Wooden case/Honeycomb Box/Fight case

Delivery Time: 15-35workdays

Payment Terms: T/T,L/C,D/A,D/P,Western Union,MoneyGram

Supply Ability: 1000set

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Product Name:	Indoor Tile Led Display	Model:	P2.5
Pixel Density:	160000	LED:	SMD415
Refresh Rate:	3840-7680hz	Working Voltage:	110-240V

Product Name:	Indoor Tile Led Display
Model:	P2.5
Pixel Density:	160000
LED:	SMD415
Refresh Rate:	3840-7680hz
Working Voltage:	110-240V

Product Description

Indoor Tile LED Screen

Box size: 500mm x 1000mm

Module size: 250mm x 250mm

Product spacing: 1.95/2.5/2.604/2.976/3.91/4.68/4.81/5.2/6.25/7.8125/8.928

Box type: sheet metal box, die cast aluminum box, aluminum plate box

Floor LED display Parameters:

Parameters	P2.5	P2.976	P3.91	P4.81	P5.2	P6.25
Module Size	250mm x 250mm
Module Resolution	100x100	84x84	64x64	52x52	48x48	40x40
Cabinet Size	Customize According to Project Site
Standard Size	500mm x 500mm / 500mm x 1000mm
Pixel Density	160000	112896	65536	43264	36864	25600
LED Encapsulation	SMD1415	SMD1415	SMD1921	SMD1921	SMD1921	SMD1921
Brightness(cd/m2)	1200-1500	1500-2000	1500-2000	1500-2000	1500-2000	1500-2000
Cabinet Material	Iron/Aluminum/Die Cast Aluminum
Refresh Rate(HZ)	3840
Product Certification	CE ROHS FCC KC
Waterproof Rating	IP54	IP54	IP54-IP67	IP54-IP67	IP54-IP67	IP54-IP67
Working Temperature	﹣25℃～50℃
Working Voltage	AC110-220V
control mode	Asynchronous control/mobile APP, WIFI, U disk, cloud platform
service life	>100,000 Hours Theoretical value

LED tile screen Scope of application:

Exhibition display: museums, planning halls, science and technology museums, exhibitions, etc;
Catering industry: hotel banquet halls, corridors, lobbies, restaurant ordering areas or important corridors, etc;
Entertainment industry: Bar T stands, main passages, private room floors, etc;
Rental industry: main stage for large-scale commercial performances, major events, wedding and birthday banquet stages, media, etc;
Education industry: school laboratories, pre employment training, kindergartens, preschool training, special education, etc;
Monitoring Center: Command Room, Dispatch Room, etc;
Real estate center: sales center, model rooms, etc;
Financial centers: stock trading centers, bank headquarters, etc;
Commercial complex: main entrance of shopping mall, central square, courtyard, children's play area, etc.

LED intelligent interactive tile screen feature:

Super strong load-bearing

Each component of the LED intelligent interactive tile screen is designed according to different mechanics, with a maximum load-bearing capacity of up to 3 tons per square meter.

Moisture proof and anti slip

The bottom shell, face mask, power line, and signal line of the HSCXLED indoor LED tile screen module are all specially designed with waterproof and moisture-proof materials. They are made of raw materials with low moisture absorption coefficients and have undergone multiple sealing treatments to have good waterproof and moisture-proof functions. The front and rear of the box can reach a waterproof level of IP45.

Super wear-resistant

The LED intelligent interactive tile screen cover is made of imported PC material, which has high wear resistance, flexibility, and good resistance to high and low temperatures. And designed according to the principles of mechanics, the face mask has good wear resistance and load-bearing function.

Interactive customization

The LED intelligent interactive floor tile screen can be equipped with built-in sensors and use UDP protocol to create interactive materials according to the interaction protocol. Each square meter box screen can have 128 sensor chips built-in, with low density, allowing for multi person interaction and point-to-point interaction.
