Die Casting Aluminum Indoor LED Display Smd Led Screen P1.667

Die Casting Aluminum Indoor LED Display Smd Led Screen P1.667

Product Details:

Place of Origin: SHENZHEN
Brand Name: HSCX
Certification: CE ROHS FCC
Model Number: P1.667

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: Fight case/Wooden case/Honeycomb Box
Delivery Time: 20-35 workdays
Payment Terms: L/C, T/T, D/A
Supply Ability: 1000Set
Get Best Price Contact Now

Detail Information

Produce Name: COB LED Display Pixels: 1.667mm
LED Type: SMD1212 Pixel Density: 360000Pixel/m2
Module Size: 320*160mm Cabinet Dimension: 640*480mm/customized
IP Grade: IP31 Refresh Rate: 1920-3840hz
Viewing Angle: 160°/160° Brightness: ≥1000cd/m²
Used: Indoor Mounted On The Wall Screen Size: Customized
Highlight:

Die Casting Aluminum Indoor LED Display

,

P1.667 Indoor LED Display

,

P1.667 smd led screen

Product Description

 full colour led display small pixel pitch LED display



P1.667mm full colour led display   HD fullcolourleddisplay



Indoor LED Display  screen for Commercial Meeting Room



SMD1212 LED display screen Indoor HD LED screen LED Display



full colour led display Features:

1. Module size:320*160mm, compatible pitch:P1.667

2. Cabinet size:640*480mm,640*640mm 960*480mm or customized,die-casting box.

3.Customized Service :
We can customize the product according to customers' needs, you just need to provide the requirements details and also specify the lamp bead brand, ic brand.

4. Installation Support:
Diversified installation and high protection level . In addition, we have processional technicalengineer provide remote assistance.

5. Quality Assurance:
Using Nationstar, Nichia, Cree,Kinglight gold and Copper Wire,big size rgb chips, long service life, low failure rate;
Original pvc plastic and even aluminum material, good toughness, high and low temperature resistance, V0 grade flame retardant, UVresistant.


Parameters:



full colour led display indoor Led Display Specification

pixel pitch 1.667
lamp SMD1212
module size(W×H) 320*160mm
module resolution(Pixel/m2) 192*96
physcial density(dot/m²) 360000
cabinet size(W×H) 640*480 mm / 640*640mm / 960*480mm or customized
scanning mode 1/48
cabinet Material Diecasting Aluminum
cabinet weight(kg) 6.8   customized
best viewing distance(m) 1.6
gray scale(bit) 14-16
IP Grade IP31
viewing angle H:160 V:160
brightness 600-900cd/㎡
contrast ratio ≥8000:1
color temperature 3200-9300k
refreshrate ≥1920-3840hz
Maximum power 600W/M2
Average power 200W/M2
Operating temperature -20-60℃
Operating Humidity 10-95%RH
Input Voltage AC110-220V±15% 50-60Hz
MTBF(Hours) 50000
Life Time(Hours) 100000



* We Can Make The OEM And ODM,Customize The Shape,Size And Lamp Bead Brand, IC Brand,*



Features of full colour led display:

1. Video frame rate(≥60 Hz), screen smoother.

2. Wide viewing angle 160° for broader reach, seamless in all direction with same image quality output

3. Front maintenance way, easy to replace module and repair components

4. Grey Level(14-16bit).



LED Chips : Nichia/Cree/Epistar/Silan/King light/Silan/KN-LIGHT All Our Brand Partners

IC : Mblock/Mingyang/Chipone/Mingwei All Our Brand Partners

Power Supply:Meanwell/Megmeet/Powerld/Rong Electronic/G-Energy All Our Brand Partners

Control Card:Novastar, Linsn, Colorlight, Huidu All Our Brand Partners

Video Processor:Novastar, Videowall All Our Brand Partners

PCB Board : Flame Retardant, Anti-Aging

Magnesium Ally Cabinet : Light Weight, Corrosion Resistance
Die Casting Aluminum Indoor LED Display Smd Led Screen P1.667 0
Die Casting Aluminum Indoor LED Display Smd Led Screen P1.667 1

Our Advantages+After-sell service

1. Use Novastar system, high level of video display control.

2. High contrast, rich color, looks smooth and vivid.

3. Strict quality control ability for full production process.

4.Providing free accessories, such as power and data cables wiring diagram.

5.Free remote control debuggine serice if you need.

6. Factory supply, best price and convenient to custom made.Online service of professional staff.

7. Service from professional engineers and sales team, save your time and effort.
